技术参数： |
|
|
|
| 型号 |
34DT500 |
38DT250 |
M22 |
| 电源频率 |
50Hz/60Hz |
50Hz/60Hz |
50Hz |
| 使用电压范围 |
120V~220V |
120V~220V |
120V~220V |
| 使用温度范围 |
-10℃~+125℃ |
-10℃~+125℃ |
-10℃~+125℃ |
| 输入功率 |
≤1.0W |
≤1.0W |
≤1.0W |
| 输出转速 |
500/600 RPM |
250/300 RPM |
250/3RPM |
| 输出力矩 |
0.6mN.m |
0.6mN.m |
2mN.m |
| 绝缘电阻 |
≥100MΩ |
≥100MΩ |
≥100MΩ |
| 绝缘强度 |
1500V/1min. |
1500V/1min. |
1500V/1min. |
| 绝缘等级 |
E |
E |
H |
| 温升 |
≤60K |
≤60K |
≤60K |
| 转向 |
CCW |
CW |
CW | |
